Description

1000 Watts Continuous Power

Voltage Input Range: 10.5-15 V DC

Voltage Output:210V - 240VAC

Output Frequency: 50 Hz 2 Hz

MODIFIED SINE WAVE INVERTER (Please note this is NOT a true sine ware inverter. This item will NOT be able tomotorized equipments such as VACUUM CLEANERS, DRILLS, PUNCH, AIR-CONDITIONER, REFRIGERATORS.

1Ac Outlets

Automatic Thermal Shutdown

Overload Protection

Extra Surge Capacity

Low Battery Alarm/Shut Off

Reverse Polarity Protection

Built-in Cooling Fan

Actual Size: 191*95*55 mm7.5*3.7*2.1 in

N.W: 1055g2.32 lb

What is a modified-sine ware inverter?

Modified-sine wave and square wave inverters are the most common types of power inverters on the market. Modified-sine wave power inverters produce a power wave that is sufficient for most devices. The power wave is not exactly the same as electricity from the power grid. It has a wave form that appears as a choppy squared-off wave when viewed through an oscilloscope.

This item is ideal for those who has tight budget because the price of true-sine wave power inverters is often significantly higher than their modified-sine cousins -- usually two to five times more.

Power Inverter DC to ACPowerusers guide

Thank you for purchasing the Power inverter. The power inverter is an ultra compact and highly portable power inverter from the leader in the field of high frequency inverter design. From the 12-voltoutle in your car to boat or other electronically equipment, the will reliably power a widely of household AC products, such as portable stereos, laptop computers, mobile photo and so on. The is design to provide you convenience that has trouble to achieve, including automatic safe protection of the inverter itself and your battery, under the extraordinary overload condition.

Read the guide before installing or using the inverter, save if for further reference.

1PlacementGuideline

For optimun operation, the inverter should be placed on a flat surface asthe floor or car under these conditions as follows:

Dry: no water or get wet in the rain

Cool: the temperature between 0C(32F)and 40C(104F)

Ventilation: at least 2 inches (5cm) clearance above and on all sides if the inverter for proper cooling.

2Usage of the Inverter

2.1turn the inverter switch to(OFF) position, and then plug the inverter DC PlugInto the car cigarette lighter socket, make sure of they are firmly linked.

2.2make sure the electrical power of the Equipments you use is under the electricalpower of the inverter. Plug the AC product you wish to operate into the AC 110V/220V outlet of the inverter and switch it on.

2.3Switch the inverter on, the green light indicates that it is working normally.

2.4The red FAULT light indicates inverter shutdown caused by low or high voltage, overload or excessive temperature.

2.5In many cases, for the limited voltage from the car cigarette lighter, it mayshutdown automatically and the FAULT Red light will recover.

3Warning and Caution

2.6The power or vlotage rating of AC product is the average power they useTVs, monitors, electric motors, and other equipments are firstly switch on. They consum more power than their power rating, having high surgerequirement on staring up. Although inverter can supply momently surgte power as high as 40% more (for example,1000W inverter can supply 1400W for the products youuse. ) But, the surge power of the equipments you use may be excess of the power supplied by the inverter, causing overloadshutdown. Specially happen when inverter supply power to several products atthe same time. Then you should switch off the electrical products, switch on the inverter, lastly switch on one by one, the products that has the peak power firstly.

2.7As the battery charge is using up, the inverter sences DC input voltage has dropped to 10.4-11V,an audio warning will appear. Then the computer or other sensitive electrical appliances should be shut down. if you ignore the sound, and the voltage drops to 9.7-10.3V,the inverter will automatic turn-off to avoid battery discharge excessively. Power Protection make it shut down, the red indicator light is turned on.

2.8Start the vehicle early for battery charging, to prevent its capacity dropping, tothe impact on vehicle starting and the battery life.

2.9Although there is over-voltage protection function of inverter, it may be damaged by excessive voltage.

2.10After continuous use, the shell surface temperature will rise to 60C, payttention to keep ventilation, objects that is susceptible to heat should be kept away from it.

4Frequently Asked Questions and solutions

4.1questions(with solution):do not work, switches light does not shine

The reasons and the proposed solution

Bad battery: check battery, according to the specific circumstances of the replacement.

Anti-contact of the outlet: check battery connections, converters may be damaged, or sent to replace the converter warranty.

Untighten junction to the DC input: check wiring cables and links, tightened the terminal contact.

4.2 Question with solution: electrical equipment does not work, the red indicator light converter

AC product power consumption is higher than rated. Solution: try to use power converters that is less than the nominal electrical power

Electrical power converter is less than nominal power or peak power is too high, will cause overload shutdown. Solution: try to use the same surge power as the inverter.

The battery is use up (with the inverter warning) Solution: Recharging or replacement of it.

High temperature caused by poor ventilation make inverter shutdown. Solution: cool it for 15 minutes and remove the items around the fan and the inverter. Put the inverter in a cool place as required. Restart it.

Input voltage is too high. Solution: check the status of charging system, battery output voltage: 12V

4.3Problem (with solution): the converter output voltage detected is too low

General measurement of the voltage meter gives small measurement range. Solution: to get the output square-ware converter applications, use the True RMS multimeter in order to obtain accurate data.

4.4Problem (with solution): The warning of the inverter

Low-voltage or over-temperature protection.

Solution: use the more coarse wire or cable to recharge the battery or reduce the length of the cable. And use the inverter under cool condition or improve the ventilation around the inverter, to make the inverter work normally.

4.5Problem (with solution): converter only can drive lower-power Ac product

The voltage attenuation by a short length of wire, solution: the use of bold wire.

4.6Problem (with solution): battery usage time is too short

AC product power consumption is higher than rated. Solution: Use a large capacity battery to make up for increased power equipment.

Old battery: solution: replace it

Battery is not charged: Solution: Have the electrical system checked

5Specifications:

Output voltage: 210V-240V frequency: 50 2HZ waveform: modified sine wave

Input Voltage: 10-15V

Under voltage form: 10.4-11.0V

Off low pressure: 9.7-10.3 V

Shutdown over-voltage:14.5-15.5 V

No-load consumption: 12V input

No-load current: < 0.3A

The greatest effect :> 90%

Continuous output power: 1000W

30 minutes of continuous Power: 1400W

Actual Size: 191*95*55 mm7.5*3.7*2.1 in

N.W: 1055g (2.32 lb)
